THE BVM BANDIT HAS EVOLVED



MADE IN THE U.S.A.


PRICE $6,099.00

Includes NEW BVM branded Servos

Final Assembly in the USA

The next evolution of the Bandit is here. A Go Fly aircraft you can grow with. Ideal for the first time jet enthusiast or the advanced jet pilot.


Vne 200mph
Limit Thrust to 100 Neutons

Specs:
Length 76"
Wingspan 69"
Weight: 21.5 #
Power: 60-100 Neutons









Special Features


  • New trailing link struts
  • High Voltage Digital Servos Installed
  • Central Control Unit for gear sequencing and brakes
  • Kevlar Fuel Tanks and Hi-Flow Fuel System installed
  • Electronic Gear and Brake Valves
  • Minimal Assembly Time
    Turbine, Receiver, UAT Installation. Radio Set-up, SD Card available for Spektrum users
  • Easy access to all components.
  • Grass field capable.

BVM Servos Now Installed in   Models

BVM servos (12kg and 32kg) are now installed in our Bandit EVO model.

The NEW BVM Servos offer a higher resolution than the previously installed servo's.

The 12kg & 32kg are HV, Digital, and Brushless.

Made by a well known manufacture in Taiwan.

Only available with a model purchase. Not available for individual sale.


  CLS 120 Specifications:
Torque @ 7.4v - 12kg/166.6oz-in
Speed @ 7.4v - 0.55 sec/60 deg
Refresh Rate: 333Hz
Motor Type: Coreless

  BLS 320 Specifications:
Torque @ 7.4v - 32.0kg/444.4oz-in
Speed @ 7.4v - 0.12 sec/60 deg
Refresh Rate: 333Hz
Motor Type: Brushless
Resolution (4096)



Controls QTY Servo Type
Steering 1 12kg

Aileron 2 32kg

Flap 2 32kg

Rudder 1 12kg

Elevator 2 12kg




 Trailing link struts, nose and main gear, allow for less than perfect landings with no damage to the model.

Pneumatic valves operate the landing gear, doors, and brakes. The electronic Central Control Unit (CCU) features fail safe low air pressure and a receiver voltage display.

NOTE: All servos are high voltage classification.



Kevlar main fuel tanks with Hi-Flow fittings and "Header" tank come installed.

"Flush Mount" overflow system installed. Fuel filter and "fuel-in" connection installed.



Control linkages for all surfaces are installed and adjusted such that they will be very close to perfect for most radios.

The engine installation utilizes a Carbon Fiber BVM "ByPass" system and double walled Stainless Steel Tailpipe for cool and reliable turbine operation.




Call 407-327-6333 to place your order or email to Patty@bvmjets.com

What is Go Fly Gold?







Items Needed To Complete:
Available from BVM

● Engine of your choice.

● BVM UAT (BVM# 6044)

● Spektrum 12310T Power Safe Receiver (# VJ-SPMAR12310T)

● (2) 7.4v Batteries 3000 mAh Magnum Ion (# VU-7304EXB-EC3)
      or   Pulse 3600mAh 2S 7.4V 15C (# V-PLURX15-36002)

● Demon Cortex Gyro Pro (# V-DA-BD-CortexPro)





Want to take the Go Fly to the next level?



Contact BVM for the Platinum pricing.



What is Go Fly Platinum?



Recommended Accessories:

Pulse Ultra Batteries for Receiver

● Fuel Pump/Filter Mount (# PA-SR-0064)

● BVM GFG Over Flow Tank (BVM # 6037)



Options:

Nose Strut Spring Upgrade

# PA-SR-0132









Aeropoxy
(BVM# 9566)

QT Poxy
(BVM# PA-SR-0042)

Slo-Zap
(BVM# PT20)

Pacer Z-42
(BVM# PT42)

Thin Lube For O'Rings
(BVM# 1945)

Dry Lube
(BVM# 1947)

Set of Wing & Tail Bags  $240.00



5 Gal GFG Fuel/Smoke System

# PA-SR-0154

$259.00





BVM Air Inflator Adaptor

# PA-SR-0153

$19.99

*This adaptor is not designed to retain pressure*





PRICE $6,099.00

Includes NEW BVM branded Servos

Custom paint schemes are available for up to a $500.00 artwork, documentation and development fee.

There are many paint scheme options that are not currently on our site.  We are working diligently to update the website with all the existing schemes. Please give us a call if you have a scheme in mind to see if it is already in our archive.



Thank you for your understanding and continued support.

Paint Schemes:

click on images to enlarge




Navy Aggressor


click here for color scheme photo


Hi Viz Aggressor



# K5500-00      BVM Anniversary



Click here for color scheme photo

# K5500-03      Rally Orange



# K5500-04      Red/White



# K5500-05      Blue Angel

Click here for color scheme photos






Customer Hotshots
click on images to enlarge



Marshal Emmendorfer with his Bandit evo.
His Bandit has a Spektrum 20 receiver, a King Tech 100 turbine, and a BVM smoke system.
