BVM F-18 1:7.75 Scale
E/F Super Hornet



PRICE $7,599.00
includes freight shipped within the USA

Includes NEW BVM branded Servos

Specifications

Length:
Wingspan:
Weight:
88"
67"
34 Lbs
  Turbine Engine:
Channels Required:
Gyro:
30 - 36 #
12 - 15
Optional


The shock absorbing landing gear is grassfield proven.

.

Special Features Installed

  • Central Control Unit (CCU)

  • Landing Gear w/Trailing Link Struts and Air System

  • Digital High Voltage Metal Gear Train

  • Servo Extensions and Linkage Rods

  • Navigation & Landing Lights

  • Fuel System

  • Doublewall Stainless Steel Thrust Tube

  • BVM Air Fill Valve

  • Air Tanks

  • Wheels and Brakes

  • Gear Valve

  • Brake Valve

  • Smoke Tank

  • Smoke Pump

  • BVM Air Gauge

  • Cockpit Deck

  • Painted In Your Choice of Available Schemes - Custom Schemes Available

  • BVM Manual

BVM Servos Now Installed in   Models

BVM servos (32kg) are now installed in our F-18 1:7.75 scale model.

The NEW BVM Servos offer a higher resolution than the previously installed servo's.

The 32kg are HV, Digital, and Brushless.

Made by a well known manufacture in Taiwan.

Only available with a model purchase. Not available for individual sale.

  BLS 320 Specifications:
Torque @ 7.4v - 32.0kg/444.4oz-in
Speed @ 7.4v - 0.12 sec/60 deg
Refresh Rate: 333Hz
Motor Type: Brushless
Resolution (4096)



Controls QTY Servo Type
Steering 1 32kg

Aileron 2 32kg

Flap 2 32kg

Rudder 2 32kg

Elevator 2 32kg









Items Needed To Complete:
Available from BVM

(2) BVM # VU-7304EXB-EC3 - HiCurrent EXB 3000 mAh w/EC3
OR
(2) BVM # TP4000-2SPXRX - ThunderPower RX 4000mAh 2-Cell/2S 7.4V



(1) BVM # 6044 - BVM Ultimate Air Trap

12 Channel Receiver minimum



Want to take the Go Fly to the next level?



Contact BVM for the Platinum pricing.



What is Go Fly Platinum?





Options:

Pulse Ultra Batteries

Warbird Pilot - Modified     $79.99
BVM # V-WB-10"/8 Jet Pilot



Set of Wing & Tail Bags   $255.00




5 Gal GFG Fuel/Smoke System

# PA-SR-0154

$259.00





BVM Air Inflator Adaptor

# PA-SR-0153

$19.99

*This adaptor is not designed to retain pressure*

Engine Choices

 Your choice of 30 - 36 Lb turbine



Call BVM for combo pricing.


Optional Gyro

NOTE: BVM prototype was flown without a Gyro.
Of course, a properly set-up Gyro smoothes things out especially in the wind.


#V-DA-BD-CORTEXPRO   Bavarian Demon Cortex Pro





List of Adhesives/Lubricants:

HeatShield BVM #PA-MA-1940

BVM Dry Lube  BVM #1947

PRICE $7,599.00
includes freight shipped within the USA

Includes NEW BVM branded Servos

Custom paint schemes are available for up to a $500.00 artwork, documentation and development fee.

There are many paint scheme options that are not currently on our site.  We are working diligently to update the website with all the existing schemes. Please give us a call if you have a scheme in mind to see if it is already in our archive.



Thank you for your understanding and continued support.



Paint Schemes:



#K3300-27
Top Gun Maverick

#K3300-21
Tigermeet Canadian of Americas 2003

#K3300-22
Redcocks

#K3300-24
Navy Test Pilot School

#K3300-26
VFC-12 Navy Aggressor Ambush Fighting Omars

#K3300-14
VFA-122 Flying Eagles Centennial of Naval Aviation

#K3300-25
Canada 150 "Maple Leaf"
Fantasy Scheme

#K3300-20
Super Bee
Fantasy Scheme

60 Years of Norad
# K3300-15

Roll Out
# K3300-17


#K3300-09
Blue Angel


#K3300-03
Black Aces


#K3300-10
Salty Dogs



#K3300-08
Bounty Hunter

#K3300-06
Navy Aggressor



#K3300-01
US Navy Diamond Back

#K3300-07
Jolly Rogers







Customer Hotshots
click on images to enlarge



Todd Cormier from Opelousas, Louisiana with his BVM F-18 1:7.75 scale Blue Angels.









Subject: Best of both worlds

Patty,
Great toys F16 1/5 with Jetsmunt 250 and F18 with Swiwin 190. Robby, Marvin and the rest of your team are amazing, that is why I buy BVM. Superior leadership, of course, Patty.


My hardest decision is picking which one to put in the car to go play with.


Bill Robinson










Patty and Heather,

I was able to get the first flights on my BVM F-18 before the end of the year and it is incredible. It is powered by a BadboyzRC Swiwin 190 and guided by a Futaba T18SZ and Advanced Radio Smooth Flight 16.



Chris Kaiser









From: Erik Rudjord
Sent: Thursday, April 27, 2023 6:22 PM
To: Patty <patty@bvmjets.com>
Subject: F-18

Patty,

I was able to maiden the F-18 today. It went perfectly! I love the jet!

Another home run by BVM jets. IX20SE guidance, and propelled by a Swiwin 190. Thank you again for everything!



Erik Rudjord




BVM 1:7.75 F-18 owner Randy Ott, Houston, TX. 2022 Top Gun Lakeland, FL








Chad Wrightson from Florida is now a proud owner of this BVM F-18 7.75.  He is all smiles after five flights on the F-18. This is powered by a Swiwin 190.






Michael Danielson with his BVM F-18 1:7.75 scale recently attended the NAMFI event in Owatonna, MN.

(L-R) Zane, Jacob, Caleb, and Mike








Hi Patty,

I wanted to send along a picture of my 1:7 F-18. You guys did an amazing job on this plane! Hats off to Rob and the BVM team for all the assistance with the maiden at Jets Over Kentucky. I have several flights on it now and it flies amazing. It’s powered by Swiwin 170 with Cortex Pro onboard along with Spektrum IX20 for guidance. Looking forward to my next BVM jet!



Thanks,

Brandon Rust










Arturo Espinoza from the golden Saltillo Coahuila Mexico on the first flight with his F-18 7.75 scale. This F-18 is powered by a KingTech 160 V2 turbine and a Jeti DS-24 radio.








Hello Patty,

I wanted to send you a photo of my second BVM model. This F-18 1:7.75 scale follows the same great lineage as my 5 year old BVM Cougar. This Hornet is powered with a King Tech K160 G2 and uses a DX 20 for guidance. Also a Demon Cortex Pro on board for the windy days. The Hornet flies faster and maneuvers quicker than the Cougar, but in the end they are both unbeatable models for any day flying and easy for one person to handle. It is the perfect hanger mate for my BVM Cougar.

Thanks again for all the great help the BVM staff is famous for.

Rod Wilkinson
Wasilla, Alaska







Marshal Emmendorfer and Steve Pully flew together at the Michigan Jet Rally in Baldwin, MI.
Marshal flew the BVM F-18 1:7.75 Scale and Steve flew his ( 15 year old ) BVM F-4.




Hi Rob, Heather and Patty,

Here are some pictures of my BVM F-18 1:7.75 Scale PNP this past weekend at MN Jets. This is a great flying model that draws a lot of comments when people get to see it. Thank you for all the continued support providing high quality models and great customer service!

Thanks,
Mike Danielson









Darren Braun from San Jose, CA is all smiles after the maiden flight this past weekend.  The F-18 1:7.75 scale PNP in the Salty Dogs scheme is powered by a KingTech K-140G2.




Chris Balling from Arizona with his BVM F-18 1:7.75 scale PNP in the Blue Angels scheme.
